SRM6-40.5 Fully Enclosed, Fully Insulated, Gas-Filled Ring Network Switchgear

The SRM6-40.5 Fully Enclosed, Fully Insulated, Gas-Filled Ring Network Switchgear is a medium-voltage power distribution unit designed for three-phase AC systems with a rated voltage of 40.5kV and a frequency of 50Hz.

Product Advantages
Completely Sealed System
All high-voltage components are enclosed in a stainless-steel tank filled with SF₆ gas to maintain insulation and arc-extinguishing properties.The sealed tank is factory-filled and requires no gas replenishment under normal operating conditions.

Modular and Compact Design
The switchgear's modular layout allows for configuration flexibility, making it adaptable to different grid topologies.Its compact footprint supports installation in confined spaces such as substations, industrial plants, and underground facilities.

Operational Security and Reliability
Internal arc fault containment and pressure relief mechanisms are incorporated to support personnel safety.The system design ensures consistent operation across varying environmental conditions, including temperature and humidity variations.

Product Features
SF₆ Gas Insulated and Metal-Clad Construction
The sealed stainless-steel tank contains load break switches, vacuum circuit breakers, and other components, all isolated from external elements.The design limits oxidation, contamination, and moisture intrusion, contributing to prolonged service life.

Flexible Functional Unit Combinations
Modules include load break switches, vacuum circuit breaker units, metering units, and cable switching units.Each module is pre-tested and assembled for seamless integration into the overall system.
