GCS Low Voltage Draw-Out Switch Cabinet

The GCS Low Voltage Draw-Out Switch Cabinet is a multifunctional low-voltage switchgear system developed to meet the operational demands of power generation, industrial control, and infrastructure projects. It is designed for use in power distribution systems with an AC 50Hz frequency, rated operational voltage up to 660V, and rated current up to 4000A. The cabinet incorporates draw-out unit technology, allowing fast module replacement and effective system management. The structure promotes a modular approach that supports varied configurations and enhances system flexibility.

Product Advantages
Enhanced Maintainability
Draw-out modules can be inspected or replaced without disconnecting the entire cabinet.Maintenance operations are simplified by clearly marked module interfaces and control points.

Flexible Modular Configuration
Standardized module units support scalable arrangements according to project requirements.Multiple cabinet forms can be combined to suit different electrical systems and layouts.

Optimized Operational Safety
Compartmental design with functional isolation helps contain electrical faults.Mechanical interlocks reduce operational risks by ensuring correct sequencing of actions.

Efficient Use of Space
Vertical arrangement of draw-out units increases density without compromising access.Compact footprint enables integration in facilities with space limitations.

Product Features
Functional Compartmentalization
Divided into separate compartments for busbars, functional units, and cable connections.Reduces the chance of cross-contamination during operation or fault conditions.

Versatile Draw-Out Modules
Each functional unit (drawer) can be independently operated, tested, or isolated.Designed for rapid installation and withdrawal, supporting standard operation positions: connected, test, and isolated.
