Removable AC Metal-clad Switchgear

KYN61-40.5 Removable Ac Metal-clad switchgear (hereinafter referred to as "switchgear”) is characterized by the configurationof ZN85-40.5, VD4, VB2 fully-insulated vacuum circuit breakers, and spring operating mechanisms inside the cabinet. The cabinet isassembled with aluminum-zinc plates, improving the precision of the trolley's coordination with the cabinet, The trolley movementis convenient, and there is strong interchangeablity. The appearance is aesthetically pleasing. The solution is comprehensive, andthe usage is safe and reliable.
This product is used in 35kV three-phase Ac 50Hz power systems, serving as a distribution room for receiving and distributingelectrical energy in power plants, substations, and industrial and mining enterprises. lt has control, protection, and monitoringfunctions.
This product complies with GB3906 "3~35kV AC Metal-Enclosed Switchgear, IEC60694&GB/T11022 "The Common Technicalclauses of High-Voltage Switchgear and controlgear Standard,’ DL/T404 'Technical Specifications for Ordering Ac High-VoltageSwitchgear," and lEC62271-200"1-52kV AC Metal-Enclosed Switchgear and controlgear standard."
